Putai High Quality Perforated Cable Tray Manufacturing Roll Forming Machine Line
-
Decoiler: To hold and feed the metal coil.
-
Punching & Notching Unit: For creating precise holes, notches, or slots for connectivity and ventilation.
-
Cut-off System: A high-speed flying cut-off that shears the formed tray to the required length without stopping the production line.
-
Control System: A programmable logic controller (PLC) allows for easy parameter setting, ensuring operational simplicity and repeatability.
Product details
Project case
Cable Tray Roll Forming Machine in Construction Application:
A cable tray roll forming machine is a continuous, automated production line designed to fabricate cable trays from coiled metal strips. Utilizing the roll forming process, it progressively shapes materials like pre-painted galvanized steel, aluminum, or stainless steel into specific profiles—such as ladder-type, trough, wire mesh, or channel-style trays—without any material removal. This method ensures exceptional consistency, strength, and dimensional accuracy across unlimited production lengths.
A typical machine is not a single unit but an integrated system, comprising several key stations:
Decoiler: Acts as the starting point, holding and feeding the heavy metal coil into the production line.
Entry Guide & Leveling Unit: Ensures the metal strip is perfectly flat and aligned before it enters the forming stations, preventing twists and imperfections.
Roll Forming Station: The core of the machine, consisting of multiple stands of precision-machined rollers. Each stand performs a minor forming operation, gradually shaping the metal into the final cable tray design.
Punching & Notching Unit (In-line): Integrated within the line, this unit uses hydraulic or servo punches to create precise holes, notches, or slots for connectivity, ventilation, or cable tie-downs.
Cut-off Mechanism: A critical component that accurately shears the continuously formed tray to the required length. Advanced "flying cut-off" systems synchronize with the moving material, allowing for clean, burr-free cuts without stopping the production line.
PLC Control System:
The brain of the operation. A Programmable Logic Controller allows operators to input parameters (length, quantity, hole patterns), monitor the entire process, and ensure repeatability for every production run.
Product parameter
|
Product name |
Cable Tray Machine |
|
Roller material |
Cr40 |
|
After-sales Service Provided |
Engineers |
|
Machine Type |
Cable Tray |
|
Shaft material |
40Cr |
|
Place of Origin |
TIANJIN |
|
Minimum order quantity |
1 set |
Product advantages
Product display
Company Introduction
Our company Bazhou chenglang factory and Putai company(Tianjin Branch) is a professional cold roll forming machine manufacturer,we have been focusing on this field for 23 years. Our equipment includes roof forming machine, floor deck machine, automatic hydraulic uncoiler machine, shutter door coiling machine, light keel cold roll forming machine,stud and track C Z U forming machine, whole equalizer machine and other related construction equipment. With more than 22 years of engineering and design research and develop team. We have two patents for independently developed machine .At the same time, our machines use brand electrical components, raw materials from brand steel mills, strict process control, two year warranty, installation and training services.
Company tenet
Our customers all over the world, such as Germany, the United States, Mexico, Chile, Bolivia, Italy, Australia, Kuwait, Saudi Arabia, South Korea, South Africa, Kenya and other countries and regions. We have rich experience in different country needs such as profiles, thickness ranges, use, installation etc.
Company tenet: technological innovation, customer - centered, win-win. Thank you for your trust and choice, we will provide you with the best service support, help you achieve greater success. We look forward to more cooperation with old and new friends from all over the world!
Our R & D team has won a number of patent certificates and quality outstanding brand awards
